HTCI EDAS FOX Laptop 17 2023
EDAS FOX LAPTOP 17′ es un Sistema Forense Integrado para la extracción y el análisis de evidencia digital (discos duros, memorias USB, computadores, teléfonos, drones, media, tablets, entre otros). Incluye herramientas para la decodificación y reporte de los datos extraídos, permitiendo además su análisis e integración con otras fuentes (CDRs, imágenes forenses, videos, fotografías, otros). El kit contiene todos los cables, dispositivos y adaptadores necesarios para la extracción segura de una evidencia digital .
Especificaciones Técnicas
- 13th Generation Intel Core i9-13900HX Processor (24 Cores, 36MB Smart Cache, 5.40GHz Turbo)
- 17.3″ QHD 240Hz, Wide View Angle, 100% DCI-P3, G-Sync Matte Display (2560 x 1440)
- NVIDIA GeForce RTX 4090 GPU with 16GB GDDR6 Video Memory
- Windows 11 Pro 64-Bit Edition Preinstalled
- 64GB Dual Channel DDR5 SDRAM at 4800MHz – 2 X 32GB
- 2TB Samsung 980 Pro M.2 PCIe Gen 4 NVMe SSD
- 2TB Samsung 970 EVO Plus M.2 PCIe NVMe SSD – Slot 2
- 2TB Samsung 970 EVO Plus M.2 PCIe NVMe SSD – Slot 3
- Killer Dual Band Wireless-AX 1650X M.2 Wireless LAN + Bluetooth Module – Fuentes de poder y batería
- Maleta rígida para transporte del equipo. Garantía un año.
- Bloqueador Forense Write Protect Portable
- Según especificaciones técnicas modelo EDAS FOX LT17 Series 2023
| Core Logic | Intel HM470 Express Chipset |
| Memory | Supports Dual Channel DDR4Two 260Pin SODIMM sockets, support for DDR4 up to 2933MHz (Real operation frequency depends on processor) Expandable up to 64GB, depends on 8GB/16GB/32GB SODIMM module. |
| Display | 15.6” Full HD (1920x1080) 144Hz, Wide View Angle, Matte Finished |
| Graphics | Switchable GPU by Microsoft Hybrid |
| Processor | Graphics - NVIDIA GeForce RTX 3060 GPU / Intel UHD Graphics NVIDIA GeForce RTX 3060, 6GB GDDR6 - Support PCIe x16 - Microsoft DirectX 12 Compatible - NVIDIA CUDA Technology - Support 4 active displays - Maximum TGP: 105 W (including 15W Dynamic Boost 2.0) Intel UHD Graphics (Integrated in Core i7- 10870H processor) - HDR Support - Rec. 2020 (Wide Color Gamut) - Microsoft DirectX 12 Compatible |
| Storage | One changeable 2.5” 7.0mm(H) HDD/SSD, SATA interface One M.2 2280 SSD, SATA / PCIe Gen3x4 interface or Two M.2 2280 PCIe Gen3x4 interface (RAID 0/1) |
| Audio System | High Definition audio interface Built-in Array Microphone 2 Built-in Speakers Sound Blaster Cinema 6 |
| Pointing Device | Integrated touchpad with Microsoft PTP multi-gesture and scrolling function |
| Keybord | Multi languages, Single Zone Multi-Color illuminated full size keyboard with numeric pad. (15 colors to select) Fully programmable macro capability - customize individual key as hot key / multiple keystrokes in one key |
| I/O Ports | I/O Ports Slots Communication Security Power System OS Support Certificate Physical Characteristic Other Features 1 HDMI output Port (with HDCP) 1 Mini DisplayPort 1.4 output Port 1 DisplayPort 1.4 over USB 3.2 Gen 2 (Type-C) 1 USB 2.0 Port (Type A) 1 USB 3.2 Port (Type A) 1 USB 3.2 Gen 2 Port (Type A) 1 2-in-1 Audio Jack (Headphone / Microphone) 1 Microphone Jack 1 RJ-45 LAN (10/100/1000Mbps) |
| Slots | 6-in-1 Push-Push Card Reader (MMC/RSMMC/SD/Mini- SD/SDHC/SDXC) Three M.2 Card Slots - 1st for WLAN Combo M.2 2230 Card with PCIe and USB interface - 2nd for SSD M.2 2280 Card with SATA / PCIe Gen3 x4 interface - 3rd for SSD M.2 2280 Card with PCIe Gen3x4 interface |
| Communication | Built-in Gigabit Ethernet LAN Intel Dual Band Wireless Wi-Fi 6 AX + Bluetooth, M.2 interface Killer Dual Band Wireless-AX 1650X + Bluetooth, M.2 interface |
| Security | Kensington Lock Intel PTT (Platform Trust Technology) |
| Power System | Removable 4 cells Smart Lithium-Ion battery pack 48.96WH Full Range AC-in 100~240V, 50~60Hz, 180W AC Adapter, DC output 19.5V, 9.23A |
| OS Support | Windows 10 (64-bit) |
| Certificate | Windows 10 (64-bit) Logo HDMI Logo |
| Physical Characteristic | 4.85 lbs including bare bone and 48.96WH Battery Pack 14.21" (w) x 10.16" (d) x 1.10" (h) |
| Other Features | Metal top case Built-in 1.0M HD Video Camera FlexiCharger Virtual Reality ready via HDMI from dGPU Windows Mixed Reality Compatible |
